- Top speed
- 3 mph
Pony Express 1052 Motorized Scissor Lift Cart
- Availability
- In stock
- Brand
- EK Tech
- Model
- 1052
Price by written quote
Price, freight to your ZIP and lead time on one sheet
- Freight to your ZIP On your quote before you order
- Built to order Then delivered by freight truck to your dock
- Fast answers We call the factory for you
- The right machine We research every option
- Send your drawings We check that it all fits
- 2 year warranty On the frame and drive, 1 year on other parts
Pick from nine hitches, or send your drawing for a custom hitch, top or deck.
Reviews of our parent store Heavy Duty Mobility
Downloads
Similar models
Other machines in this line, nearest in capacity
-
Pony Express 1065-LS Linen and Laundry Tugger
Top speed3 mph
Run time per charge8 hours
BatteryDeep cycle AGM batteries provide over 2 times the life of standard AGM batteries
In stock
View model
-
Pony Express 1062-LS Linen and Laundry Tugger
Top speed3 mph
Run time per charge8 hours
Battery35 Ah deep cycle AGM
In stock
View model
-
Pony Express 1040 Motorized Platform Cart
Top speed3 mph
Run time per charge8 hours
Battery35 Ah AGM
In stock
View model
Highlights
-
Lifts 2,000 or 2,500 lb
-
24, 36 or 48 inches of vertical travel from 17.5 inches
-
Crawl speed whenever the platform is raised
-
Platforms up to 36 by 84 inches
Where it works
-
Plants
Parts and dies raised to press and bench height.
-
Warehouses
Cartons lifted to conveyor and shelf height.
-
Assembly
Work held at the right height at each station.
-
Packaging lines
Product raised to the packing and conveyor level.
Specifications
Performance
| Load capacity | Ask us |
|---|---|
| Top speed | 3 mph |
| Variable speed range | 0 to 3 mph, hi/low speed switch |
| Crawl speed | 25% of normal speed when the platform is not fully down |
Battery and charging
| Run time per charge | Ask us |
|---|---|
| Battery | Deep cycle AGM |
| Range per charge | Up to 5 miles of operation on a single charge |
Size and weight
| Platform length | 40 to 84 in |
|---|---|
| Platform width | 26 to 36 in |
| Lowered height | 17.5 in |
More details
| 1052-2000-24 | 2,000 lb, 24 in travel, 7 s lift, 17.5 to 41.5 in, standard platform 26 x 40 in, maximum 36 x 60 in |
|---|---|
| 1052-2500-24 | 2,500 lb, 24 in travel, 8 s lift, 17.5 to 41.5 in, standard platform 26 x 40 in, maximum 36 x 60 in |
| 1052-2000-36 | 2,000 lb, 36 in travel, 9 s lift, 17.5 to 53.5 in, standard platform 26 x 48 in, maximum 36 x 72 in |
| 1052-2500-36 | 2,500 lb, 36 in travel, 11 s lift, 17.5 to 53.5 in, standard platform 26 x 48 in, maximum 36 x 72 in |
| 1052-2000-48 | 2,000 lb, 48 in travel, 19 s lift, 17.5 to 65.5 in, standard platform 26 x 64 in, maximum 36 x 84 in |
| 1052-2500-48 | 2,500 lb, 48 in travel, 21 s lift, 17.5 to 65.5 in, standard platform 26 x 64 in, maximum 36 x 84 in |
| Electrical | 120/240 VAC, 50/60 Hz |
Documents
Warranty
For the Pony Express 1052 Motorized Scissor Lift Cart
- 2 years Frame and drive
- 1 year Other parts
Returns and changes
- Return within 30 days with a return authorization number
- Cancel free before it ships
- Return freight on the original pallet is yours, with a 20% restocking fee after it ships
- Any damage to a returned machine is charged to you
- Custom builds are final
Questions about coverage? Call us 1-888-441-8992
Reviews of our parent store Heavy Duty Mobility
Call 1-888-441-8992
Ask for Raphael
He even called me right after I placed the order online to review everything…
Veronica Trustpilot
He really knows his products, was really quick looking up the answers…
Michele Stern Google
Thank you so very much for offering a much better solution for my unique situation…
LuAnn Lozano Trustpilot
Your company was great… from the ordering to the delivery.
Sheila Nelson Google
Great customer service they follow up and go the extra mile…
Jeff Spann Google
1 of 6
How we work
-
You call or send the form
Tell us what you move and where. Add drawings if you have them.
-
We check your route
Every door, ramp, turn and elevator, before we quote.
-
We call the factory
We call the maker ourselves for build dates and answers.
-
You get a written quote
It lists the machine, options, freight and build time.
-
Approve and we order
We order from the factory and tell you the ship date.
Overview
The Pony Express 1052 puts a battery powered hydraulic scissor table on a self-propelled base. The operator loads it low, drives it across the plant at up to 3 mph, and raises up to 2,500 lb to the height the next station needs.
It comes in six standard builds. Each pairs a 2,000 or 2,500 lb capacity with 24, 36 or 48 inches of vertical travel. Every build starts at a 17.5 inch lowered height and rises to 41.5, 53.5 or 65.5 inches. Standard platforms are 26 inches wide and 40, 48 or 64 inches long, and platforms up to 36 by 84 inches are available.
Crawl speed keeps a raised load under control. Whenever the platform is off its lowest position, drive speed drops to a quarter of normal, so the operator can still inch the cart into place. The cart can also be set up to stop all travel while the platform is raised.
On board batteries give up to 5 miles of operation on a charge, with no AC power needed except to recharge. Hand controls are on a pendant, and a horn, key switch and emergency stop come standard.
Options
- Ball transfer top
- Rotating top
- Conveyor top, including double level roller decks
- Stainless steel top
- Accordion safety skirting
- Safety sensing edges and collision detection
- Foot control switch
- NEMA or IP rated electronics enclosure
- Higher capacity battery pack
- Capacities above 2,500 lb and larger platforms
Questions
Which 1052 build do I need?
Start with the heaviest load and the height it has to reach. The 24 inch travel builds rise to 41.5 inches, the 36 inch builds to 53.5 inches and the 48 inch builds to 65.5 inches, each at 2,000 or 2,500 lb. Send us the load and the station height and we name the build.
Can I drive the cart with the load raised?
Yes, at reduced speed. Crawl speed limits travel to a quarter of normal whenever the platform is not fully down. The cart can also be set up to stop all travel while the platform is raised.
What platform sizes are available?
Standard platforms are 26 inches wide and 40, 48 or 64 inches long, depending on the travel. Platforms up to 36 by 84 inches are available, and so are ball transfer, rotating, conveyor and stainless steel tops.
How far does it go on a charge?
Up to 5 miles of operation. A higher capacity battery pack is available when the cart works a longer route.
How do I get a price?
Call us or send the form. Tell us what you move, the route and your ZIP. We send a written quote with the machine, freight and build time.
How does it arrive?
Most machines go by freight truck from the factory. Parts and smaller items can go by FedEx or UPS. Freight to your ZIP is on your quote before you order. Rush and overnight shipping cost extra. We sell and ship to US addresses only.
